KRAUSS MAFFEI

KM50-180AX

50t injection molding machine

Category	10 to 99t Injection moulding machines
Condition	Used
Year	2013
Availability	Available
ID	11329

Isaac Mateo

+34 932 711 191

|

+34 652 098 501

Clamping force

0kN

Clamping force	500 kN
Air Valves	2
Control	MC5
Core pullers	2
Dimensions (long x wide x high)	4.400 x 1.600 x 1.900 mm
Distance between tie-bars (h x v)	410 x 360 mm
Heating zones	10
Injection pressure	2.500 bar
Injection volume	59 cm³
Mould height max	470 mm
Mould height min	150 mm
Mould opening stroke max	300 mm
Operating hours	29.000
Platen size (h x v)	510 x 460 mm
Power: installed max	8,1 kW
Screw diameter	25 mm
Shot weight max	54 g
Weight	3.700 kg

KRAUSS MAFFEI KM50-180AX	View PDF
KRAUSS MAFFEI KM50-180AX Machine Layout	View PDF
