NISSEI ASB

PF8-4B

PET Injection stretch blow molding machine

Category	PET Injection Blow Moulding
Condition	Used
Year	2009
Availability	Available
ID	11284

Isaac Mateo

+34 932 711 191

|

+34 652 098 501

with chiller & dehumidifying dryer

Blow Clamping Force	242 kN
Body Diameter max.	89 mm
Capacity max.	1,5 l
Cavity Number	8
Dimensions (long x wide x high)	5.985 x 2.100 x 2.955 mm
Injection Clamping force	460 kN
Injection volume	515 cm³
Neck Diameter max.	30 (36) mm
Oil tank capacity	450 l
Power: installed max	34 + 39.9 kW
Screw diameter	64 mm
Shot weight max	55 g
Support Ring Diameter max.	34 (42) mm
Thread Diameter max.	32 (38) mm
Weight	10.500 kg

NISSEI ASB PF8-4B Official Catalogue	View PDF
