NEGRI BOSSI

CANBIO V530 - 4100

530t injection molding machine

Category 500 to 749t Injection moulding machines
Condition Used
Year 2004
Availability Sold
ID 10665
Sold

Clamping force5.300 kN
ControlNEGRI BOSSI BR
Daylight between platens max830 mm
Dimensions (long x wide x high)9.510 x 2.150 x 2.375 mm
Distance between tie-bars (h x v)900 x 800 mm
Heating zones5
Injection pressure1.620 bar
Injection rate500 cm³/s
Injection volume2.540 cm³
Mould height max850 mm
Mould height min300 mm
Nozzle stroke / force max.121 mm / kN
Operating hours33.500
Platen size (h x v)1.310 x 1.260 mm
Power: installed max34 + 55 kW
Screw diameter90 mm
Screw L/D ratio20
Screw speed175 rpm
Shot weight max2.270 g
Weight23.000 kg

NEGRI BOSSI CANBIO V530 - 4100 Official Catalogue View PDF
NEGRI BOSSI CANBIO V530 - 4100 Official Catalogue View PDF
