ENGEL

VICTORY VC 330 / 80 SPEX

80t injection molding machine

Category 10 to 99t Injection moulding machines
Condition Used
Year 2017
Availability Sold
ID 10637
Sold
Clamping force

0kN

INCLUDES:
- EcoDrive energy saving pack.
- 40mm bimetallic screw.
- Core pullers.
- 8 water circuits with connection on the machine plates.
- Additional second BRAND NEW complete injection unit (30 or 35mm. The original price was 20.000 EUR).

OPTIONAL:
- Wittmann ROBOT (2017) not included in the price.

Clamping force800 kN
Core pullersyes
Daylight between platens max700 mm
Dimensions (long x wide x high)3.900 x 1.500 x 2.000 mm
Injection pressure1.670 bar
Injection volume201 cm³
Mould height max450 mm
Mould height min150 mm
Mould opening stroke max450 mm
Nozzle stroke max250 mm
Oil tank capacity185 l
Operating hours23.861
Platen size (h x v)670 x 600 mm
Power: installed max25 kW
Screw diameter40 mm
Screw speed320 rpm
Shot weight max185 g
Weight5.200 kg
