ENGEL

VICTORY VC 330 / 150 TECH PRO

150t injection molding machine

Request a quote
Category 100 to 249t Injection moulding machines
Condition Used
Year 2005
Availability Available
ID 10125

Screw diameter25 mm
Shot weight max72 g
Injection rate77 cm³/s
Injection pressure2.400 bar
Injection volume78 cm³
Screw speed400 rpm
Screw L/D ratio24.8
Nozzle force max47 mm / kN
Nozzle stroke max250 mm
Clamping force1500 kN
Mould opening stroke max600 mm
Mould height min300 mm
Daylight between platens max900 mm
Platen size h750 mm
Platen size v520 mm
Ejector force61 kN
Oil tank capacity450 l
Operating hours44.574
