ENGEL

ES 750 / 300 HL PRO SERIES

300t injection molding machine

Category	250 to 499t Injection moulding machines
Condition	Used
Year	2003
Availability	Available
ID	10450

Isaac Mateo

+34 932 711 191

|

+34 652 098 501

Clamping force	3.000 kN
Control	CC100
Daylight between platens max	1.200 mm
Dimensions (long x wide x high)	6.700 x 2.000 x 2.300 mm
Ejector stroke / force max.	200/83 mm / kN
Injection pressure	2.360 bar
Injection rate	230 cm³/s
Injection volume	318 cm³
Mold opening force	196 kN
Mould height min	350 mm
Mould opening stroke max	850 mm
Nozzle stroke / force max.	350/67 mm / kN
Oil tank capacity	810 l
Platen size (h x v)	1050 x 650 mm
Power: installed max	55 kW
Screw diameter	45 mm
Screw speed	230 rpm
Shot weight max	293 g
Weight	21.000 kg
