ENGEL

ES 200 / 45 HL PRO SERIES

45t injection molding machine

Category 10 to 99t Injection moulding machines
Condition Used
Year 2003
Availability Sold
ID 10123
Sold

Clamping force450 kN
Daylight between platens max530 mm
Ejector force40 kN
Injection pressure2.090 bar
Injection rate88 cm³/s
Injection volume69 cm³
Mould height min180 mm
Mould opening stroke max350 mm
Nozzle stroke / force max.28 mm / kN
Nozzle stroke max200 mm
Oil tank capacity115 l
Operating hours9.800
Platen size h550 mm
Platen size v330 mm
Screw diameter25 mm
Screw L/D ratio24,8
Screw speed480 rpm
Shot weight max62,1 g
