MYNX 6500 / 50II

Vertical machining center

Category	Machining centres
Condition	Used
Year	2020
Availability	Available
ID	11312

Isaac Mateo

+34 932 711 191

+34 652 098 501

- Auto power-off - Air blower - Chip conveyor - Spindle cooling (oil cooler) - 30 ATCs - Bucket

Dimensions (long x wide x high)	3.350 x 2.674 x 2.840 mm
Max. spindle speed	6000 rpm
Max. tool dia. tool dia. with adjacent positions empty	130 mm
Max. tool diameter	95 mm
Max. tool length	300
Max. tool weight	15 kg
Max. workpiece weight	1000 kg
Number of tool stations	30
Rapid Traverse (X x Y x Z)	30.000 / 30.000 / 24.000 mm/min
Spindle power	22 / 18.5 kW
Spindle taper	ISO 50
Torque	404 Nm
Travel (X x Y x Z)	1.270 x 670 x 625 mm
Weight	9000
Working area (X x Y x Z)	1.400 x 670 mm
